HDMI Splitter 16 port 2k 4k

HDMI Splitter 16 Port 2K 4K

Detail

The HDMI Splitter 16 Port 2K 4K offers high-performance distribution of one HDMI signal input to sixteen HDMI output ports, supporting advanced video and audio formats. This splitter is ideal for large-scale multimedia installations, including conference rooms, training facilities, and digital signage, where multiple displays need to receive the same HDMI signal simultaneously.

Key Features:

1. 16-Port HDMI Splitter: Distributes one HDMI input signal to sixteen output devices, allowing multiple screens to display the same content at once.
2. Resolution and Formats:

• 4K2K Resolution: Supports high-definition 3840×2160 at 30Hz, ensuring crystal-clear video quality.
• Full 3D Support: Ideal for immersive viewing experiences in environments like home theaters and conference rooms.
• Deep Color Support: 8/10/12-bit color for vibrant and detailed visuals.

1. Audio Support:

• High-Definition Lossless Audio: Includes DTS-HD, Dolby TrueHD, DTS, Dolby AC3, and DSD formats for superior audio quality.

1. Bandwidth and Performance:

• Max Bandwidth: 320MHz
• Max Baud Rate: 3.4Gbps for smooth, high-quality video transmission.

1. Cable Distance:

• Input HDMI Cable Distance:
• ≤10m for 1080p resolution
• ≤5m for 4K resolution using AWG26 HDMI standard cable
• Output HDMI Cable Distance:
• ≤15m for 1080p resolution
• ≤10m for 4K resolution using AWG26 HDMI standard cable

1. Power Requirements:

• Power Adapter: AC (50Hz, 60Hz) 100V-240V; Output: DC12V/2A
• Max Working Current: 500mA

1. Operating Conditions:

• Temperature Range: -15 to +55°C
• Humidity Range: 5% to 90%RH (No Condensation)

1. Physical Specifications:

• Dimensions: 18.11’’ x 5.90’’ x 1.57’’
• Weight: 1680g

Operating and Connecting:

1. Connection:

• Connect one HDMI cable from HDMI source devices (e.g., DVD players, HD TV, projectors) into the HDMI Splitter input.
• Connect sixteen HDMI cables from each display (monitors or projectors) into the HDMI Splitter outputs.

Package Includes:

• 1 x 16 Port HDMI Splitter
• 1 x Power Adapter
• 1 x User Manual

This HDMI splitter is designed to provide seamless distribution of high-definition video and audio signals across multiple screens, making it a powerful solution for enhancing multimedia presentations, video conferencing, and digital signage applications.
